ABS vs PETG: Heat Resistance Showdown

Category	ABS (Example: ABS-M30) [a]	PETG (Representative Copolyester) [b]
What “Heat Resistance” Usually Means	Keeps shape closer to higher temps, especially under load	Stays tough and stable up to a point, then softens sooner under load
Glass Transition Temperature (Tg)	108°C	≈80°C
Heat Deflection Temperature (HDT) @ 0.455 MPa (66 psi)	96°C	70°C
Heat Deflection Temperature (HDT) @ 1.82 MPa (264 psi)	82°C	64°C
Vicat Softening Temperature	99°C	74°C
What Happens First When It Gets Too Warm	Warping / creeping if the part is stressed or unevenly heated	Slow bending / creep under stress as it approaches Tg
Typical Print Setup When Heat Matters	Stable chamber temperature helps a lot; drafts are the enemy	More forgiving; drafts matter less, but temperature swings still show up
Where It Commonly Shows Up	Functional housings, brackets, parts near warm electronics, fixtures	Functional parts needing toughness and easier printing, moderate heat zones

Numbers above are datasheet values, not universal “guarantees.” Real parts depend on geometry, load direction, print settings, and how long the heat is applied.

ABS and PETG can both feel “strong” in your hand, but heat changes the game fast. The real showdown isn’t only about a single temperature. It’s about time, load, and how close the part gets to softening while it’s doing real work.

⚠️ If a part is holding weight (even a small constant force), it can start deforming below the headline temperature on a spec sheet. This is why “HDT,” “Vicat,” and “Tg” are worth knowing.

ABS Printing For Heat

PETG Printing For Heat

Pick The Winner

FAQ

🔥 Heat Resistance Metrics That Matter

Three numbers show up again and again when people talk about temperature resistance: Heat Deflection Temperature (HDT), glass transition temperature (Tg), and Vicat softening temperature. They measure different things, and mixing them up is how “this should work at 90°C” turns into a bent part.

HDT is a standardized way to say: “At this stress level, the material reaches a specified deflection at a specific temperature ramp.” The key phrase is at this stress level. That’s why datasheets list multiple HDT values at different loads. [c]

Tg: the temperature region where an amorphous polymer transitions from glassy (stiff) toward rubbery (more mobile). For many filaments, this is where creep accelerates.
HDT: practical for “loaded parts” because it bakes in a stress level (like 0.455 MPa vs 1.82 MPa).
Vicat: a softening point test with a penetrator; useful as a “surface softening” signal, but it still isn’t a universal service limit.

🧠 How To Read A Datasheet Without Guessing

Match the test to your reality: is the part loaded or mostly free-standing?
Look for the stress level: HDT at 1.82 MPa will be lower than HDT at 0.455 MPa for the same material.
Give yourself margin: if your part will sit near heat for hours, treat “close to Tg” as a warning zone, not a target.
Remember print direction: layer orientation can act like a built-in weak axis when the part is warm.

🧪 ABS Under Heat: Why It Usually Holds Shape Longer

ABS is an amorphous terpolymer (acrylonitrile, butadiene, styrene). Practically, that means it doesn’t have a sharp melting point the way crystalline plastics do, but it does have a very meaningful glass transition region. Many ABS types show a Tg feature around 100–105°C, and some grades show multiple transitions tied to the different components. [d]

💡 ABS often “wins” heat resistance in the real world not because it never softens, but because it stays dimensionally stubborn longer before creep becomes obvious.

Loaded brackets and mounts: ABS tends to tolerate higher temperatures before slow bending becomes noticeable.
Warm electronics zones: housings near heat sources often behave better when Tg is higher.
Fixtures and jigs: especially where the part is clamped or squeezed and heat is present.

One detail people feel immediately: ABS can be more sensitive to internal stress from printing. If the environment cools unevenly, warping shows up early. Heat resistance and print stability are connected more than most people expect.

🧊 PETG Under Heat: Tough, Practical, And Earlier Softening

PETG (glycol-modified PET) is popular because it balances strength, toughness, and print friendliness. Thermally, the big headline is its Tg range. Eastman’s published PETG copolyester family data commonly places Tg around 80–84°C, which is a strong clue for when creep can start to speed up in warm environments. [e]

Short bursts of heat: PETG can handle brief warmth well if it’s not loaded heavily.
Moderate warm zones: parts that see “warm to the touch” conditions often do fine.
Impact-prone parts: PETG’s toughness can be a nicer fit when temperature isn’t extreme.

⚠️ PETG can feel strong at room temperature, then slowly sag when it’s warm and stressed. If your design has constant load (hanging, clamping, bending), treat the “around Tg” zone with extra respect.

🧷 Load, Creep, and Part Geometry

Heat resistance is not just “Will it melt?” It’s “Will it move?” Most real failures are slow: the part holds up, then gradually drifts out of tolerance. That’s creep. And creep is brutally sensitive to temperature + time + stress.

🔍 What Makes A Warm Part Bend Faster

Thin walls and long unsupported spans.
Load direction aligned with weaker layer bonding.
Stress concentrators: sharp corners, notches, small screw bosses.
High local heat: a single hotspot can soften one region and start a chain reaction.
Infill that looks strong but leaves thin outer skins doing the real work.

If you want a part to stay straight when warm, geometry usually beats material upgrades at first: add ribs, thicken load paths, increase contact area, and reduce leverage. Then pick the filament that supports the temperature you can’t design away.

🏠 ABS Printing For Heat: Stability First, Then Strength

ABS earns its heat reputation, but it asks for a controlled environment. A practical baseline many profiles use is a nozzle around 255°C and a bed around 100°C, with bed ranges adjusted by object size and an enclosure strongly recommended to prevent drafts and warping. [f]

Enclosure mindset: not for looks—this is about keeping the part’s temperature even while it forms.
Cooling discipline: too much cooling can “freeze” stress into the part; too little can blur details. Aim for consistent, not extreme.
Orientation for heat: place layer lines so the warm load is carried through continuous roads, not across layer interfaces.
Wall count beats infill: in warm parts, extra perimeters often outperform high infill percentages.

✅ If ABS is warping, treat that as a thermal stress alarm. The same internal stress that causes warp can also show up later as creep when the part lives in heat.

🌬️ PETG Printing For Heat: Strong Prints With Less Drama

PETG is usually easier to get “good enough” prints from, but heat-focused printing still benefits from discipline. A solid reference point from a PETG FFF technical datasheet is 230°C ± 10 for nozzle temperature and 80°C ± 10 for bed temperature, plus measured HDT values that help frame realistic expectations. [g]

Layer bonding: PETG often bonds well, but too much heat can increase stringing and surface artifacts—keep it balanced.
Cooling as a tool: moderate cooling can sharpen details; lower cooling can improve bonding. Match it to the geometry.
Support strategy: PETG can grab onto surfaces strongly, so build plate protection and release methods matter for clean removal.
Heat reality check: if your design will sit under constant load near the upper warm zone, consider stepping up to ABS (or redesigning the load path).

🏁 Pick The Winner: Heat Resistance Showdown By Scenario

🥇 ABS Is Usually The Better Call When

The part is loaded and warm (clamped, bolted, hanging, springy, or under constant force).
The environment can creep above the PETG comfort zone for long periods.
Dimensional stability matters more than a “nice, easy print.”

🥈 PETG Often Wins When

You need a tough functional part, but the heat is moderate and loads are reasonable.
You want a reliable print workflow with fewer environment controls.
The part may get bumped or dropped, and toughness is a priority.

🧩 A simple rule that holds up: if the part will be warm and stressed for hours, prioritize HDT and Tg. If it will be warm but mostly unstressed, PETG can be perfectly practical.

❓ FAQ

Is HDT the same as “maximum service temperature”?

No. HDT is measured under a defined load and deflection rule. Real service temperature depends on your part’s geometry, stress, time at temperature, and print orientation.

Why does PETG sometimes sag even below its “heat resistance” reputation?

PETG can stay tough while still getting more flexible as it approaches Tg. Under constant load, that flexibility can become slow deformation (creep).

Why do datasheets list two HDT numbers?

They’re measured at different stress levels (for example 0.455 MPa and 1.82 MPa). Higher stress usually means a lower HDT because the material reaches the defined deflection sooner.

Does print orientation change heat performance?

Yes. If a warm load pulls “across layers,” the part can soften and deform earlier. Align the main load path with continuous extrusion lines when possible.

What matters more for warm functional parts: infill or walls?

Often walls (perimeters). Warm deformation tends to start at skins and load paths. More perimeters can improve stiffness and heat-shape retention more reliably than simply increasing infill.

Can I rely on one PETG or ABS number for all brands?

No. Additives, modifiers, colorants, and the exact resin grade can shift behavior. Use datasheets as reference points, then validate with a small real-world test print for your geometry.
